Model

Model: CS-H3c-R100-1K2WF

Camera

Image Sensor: 1/2.7” Progressive Scan CMOS

Minimum Illumination: 0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR

IR Night Vision Distance: Up to 98 ft / 30 m

Shutter Speed: Self-adaptive shutter

Lens: 4mm @ F2.0, view angle: 82° (Horizontal), 98° (Diagonal)

Lens Mount: M12

DNR: 3D DNR

WDR: Digital WDR

Day / Night Switch: IR-Cut filter with auto-switching

Video & Audio

Max. Resolution: 1080p, 1920 × 1080

Frame Rate: Max: 30fps; Self-Adaptive during network transmission

Video Compression: H.265 / H.264

Video Bit Rate: Full HD; HD; Standard. Adaptive bit rate.

Audio Bit Rate: Self-Adaptive

Max. Bitrate: 2 Mbps

Network

Wi-Fi Standard: IEEE802.11b, 802.11g, 802.11n

Frequency Range: 2.4 GHz ~ 2.4835 GHz

Channel Bandwidth: Supports 20 MHz

Security: 64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK

Transmission Rate: 11b: 11Mbps, 11g: 54Mbps, 11n: 144Mbps

Wi-Fi Pairing: AP Pairing

Protocol: EZVIZ Cloud Proprietary Protocol

Interface Protocol: EZVIZ Cloud Proprietary Protocol

Wired Network: RJ45 × 1 (10M / 100M Adaptive Ethernet Port)

General

Dimensions: 72mm × 72mm × 157mm (2.83 × 2.83 × 5.98 inch)

Package Dimensions: 227 × 100 × 92 mm (8.94 × 3.94 × 3.62 inch)

Weight: Net weight: 250 g (8.82 oz), With Package: 447 g (15.77 oz)

IP Grade: IP67

Operating Conditions: -30 °C to 50°C ( -22 °F to 122 °F ), humidity 95% or less (non-condensing)

Function

Detection: AI-Powered Human Shape Detection, Motion Detection

Customized Alert Area: Supports

Integration: Works with Alexa, Google Assistant, IFTTT

General Function: Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark

Storage

Local Storage: Supports microSD card (Up to 512 GB)

Cloud Storage: Supports EZVIZ CloudPlay storage (Subscription required)

Power

Power Supply: DC 12V / 1A

Power Consumption: Max. 6W

In the Box

• H3c Camera
• Drill Template
• Screw Kit
• Waterproof Kit
• Power Adapter
• Regulatory Information
• Quick Start Guide

Warranty

Warranty: 2 Years
